FEATURES
- Made of stainless food steel DIN 1.4301 (AISI 304)
- Standardized dimensions and equipment, or according to individual customer requirements
- Interior Shell: SUS304 full welded; TH=4mm
- Exterior Shell:SUS304 full welded; TH=2.5mm
- 100% TIG welding with pure argon gas shield
- Interior Finish: Overall polishing to 0.4~0.6 μm without dead corner
- Insulation: Polyurethane; TH=80mm
- Glycol Jacket on side wall
- Stringent tank leakage test by water and pressured gas
- Stringent Jacket leakage test by water and pressured gas
- Flanged manway on top
- CIP arm with 360° coverage CIP spraying ball
- Full sanitary sampling valve
- Mechanical relief valve 2 bar on CIP arm
- Carbonation port with stone
- Shockproof pressure gauge on CIP arm
- Tri clamp discharge arm with butterfly valve
- Thermowell for high accuracy temperature sensor
- 3 or 4 pcs completely SUS304 heavy duty legs with leveling pad
- Sanitary level tube with stainless steel ball valves
- Complete valves, fittings and all parts
PARAMETERS
| Model | HG-FJ-1000L |
| Capacity | Useful capacity: 1000L; Gross capacity: 1250L |
| Material | SUS304 |
| Application | Restaurant, bar, hotel, brewery |
| Out size | Ø1260*2800mm |
| Cooling method | Jacket section cooling |
| Thickness | Inner: 3.0mm; External2.0mm |
| Outrigger | Ø102mm*4 |
| Test pressure | 0.3Mpa |
| Working pressure | 0.2Mpa |
| Heat exchange area | 3m2 |
| Weight | 450kg |
