FEATURES
- Hygienic design ensures simple and efficient cleaning
- Eccentric screw pump for mashing-in: malt to water ratios of up to 1:2 (without rinsing) can be reliably handled
- Level control in mash hopper for low oxygen uptake
- Optimized spray geometry to reduce mash flotation
- Quality automation system: feed roller speed control based on grist throughput rates provides adjusted steeping time for “harder” malt batches
- Steeping water temperature and flow are individually adjustable
- Precise and easy adjustment of the crushing roller gap
- Large rollers for optimal crushing and husk conservation
- Mash acidification is possible directly in the mill
- On request, inert gas flushing can be accommodated
- Less ATEX protection measures required because of the wet grist
PARAMETERS
| Power(KW) | Rotating speed(RPM) | Capacity(kg/h) |
| 7.5/11 | 0~6000 | 50~500 |
| 15/18.5 | 0~4500 | 200~1000 |
| 30/37/45 | 0~4000 | 500~5000 |
| 7.5/11 | 0~6000 | 50~500 |
| 15/18.5 | 0~4500 | 200~1000 |
| 30/37/45 | 0~4000 | 500~5000 |
| 75/90 | 0~3000 | 5000~10000 |
